WLC0745 Load Cell，200~2000kg

Compact design and low installation height
High overall accuracy up to C6
Stainless steel, laser welded and sealed with IP68 protection
Suitable for platform scales, tank weighing, etc

Features：

Compact design and low installation height

High overall accuracy up to C6

Stainless steel, laser welded and sealed with IP68 protection

Suitable for platform scales, tank weighing, etc

技术参数 Technical parameters					单位
额定量程	Rated capacity		200 / 300 / 500 / 1000 / 1500 / 2000		Kg
精度等级	Accuracy class		C3	C6
最大检定分读数	Maximum number of LC intervals		3000	6000
最小检定分度数	Minimum number of LC intervals		Emax/5000	Emax/10000	g
零点温度系数	Temp. Effect on zero balance		±0.0028	±0.0014	% of E_max/℃
灵敏度输出	Rated Output		2.0		mV/V
灵敏度输出误差	Rated Output tolerance		±0.1		% of E_max
零点输出	zero balance		±1.0		% of E_max
灵敏度温度系数	Temp. Effect on rated output	+20℃~+40℃	±0.00175	±0.00087	% of AL/℃
		-10℃~+20℃	±0.00117	±0.00058
滞后	Hysteresis error		±0.0167	±0.0083	% of E_max
非线性	Non-linearity error		±0.0167	±0.0083	% of E_max
蠕变	Min. Dead load output return		±0.0167	±0.0083	% of AL
输入阻抗	Input resistance		350±3		Ω
输出阻抗	Output resistance		350±3		Ω
绝缘电阻	Insulation resistance		＞5000		MΩ
建议激励电压	Recommended voltage		10		V AC/DC
最大激励电压	Max. excit. voltage		15		V AC/DC
温度补偿范围	Temp. Compensated range		-10 ~ +40		℃
使用温度范围	Operating temp. Range		-30 ~ +65		℃
存储温度范围	Storage temp. Range		-40 ~ +80		℃
安全过载	Safe overload		150%		% of E_max
极限过载	Ultimated overload		300%		% of E_max
防护等级	Protection class		IP68
密封方式	Sealing method		激光焊接密封
材质	Materials		不锈钢
防爆证书	Ex Approval		Ex ia IIC T4 Ga / Ex ia IIIC T135℃ Da
电缆长度	Cable length		2.5		m
推荐安装力矩	Recommended torque		98		N.m
